BYM 102B BUTTON BYM

BYM 102B BUTTON BYM

Kategoria
PËRSHKRIMI

GENERAL  FEATURES

  • Controlled by electro mechanic
  • Easy to dismount and mount washing / rinsing arms  and filters  for cleaning purposes,
  • Safety system to stop the operation when the door is opened,
  • Rack dimensions  500×500 mms.
  • Temperature safety thermostats  of tank and boiler ,
  • AISI 304 Cr-Ni S/S
  • Complete with 1 pc glass rack
  • 1 pc plate rack
  • 1 pc cutlery  rack
  • When  necessary, possibility to install rinsing pump where the water pressure is not sufficient  and drain pump where the level of drain is high ,
  • Optional rinsing aid, detergent, draining and booster pump .
  • Water level in the tank controlled by presosstat automatically ,
  • Starting the machine  through door .
SPECIFIKIMI TEKNIK

TECHNICAL SPECIFICATIONS

Water inlet 3/4 inches
Water pressure 2-4 Bar
Power inlet 230-50

208 -60

V-Hz.
Washing Motor Power 0,45 kW
Max. Electric Power 4,95 kW
Frequency 50-60 Hz
Water consumption 3 Lt/cyc
Tank Power 2,7 kW
Boiler Power 4,5 kW
Washing  temperature 55 °C
Rinsing temperature 85 °C
Water Inlet Temperature 45-55 °C
Boiler Volume 6 lts
Tank  Water Volume 20 lts
Plate   Capacity 540 pcs/h
Rack  Capacity 40 pcs/h
Glass Capacity 1440 pcs/h
Tray Capacity 360 pcs/h
Max. Plate Diameter 320 mms
Plate  Height 280 mms
Program Number 3 pcs
Short Program 90 sec
Medium Program 120 sec
Long Program 180 sec
Cable cross section 3×2,5 mm2
Weight 50 kgs
Rinsing  Motor Power 0,33 kW
Draining  Motor Power 31W 50Hz. / 37W 60Hz. watts
Detergent  Pump Power 8 watts
Rinsing Aid Pump Power 8 watts

Brand

Inoksan
