BYM 42B BUTTON BYM

BYM 42B BUTTON BYM

BYM 42B BUTTON BYM

Kategoria

GENERAL SPECIFICATIONS

  • Suitable for undercounter installation
  • Controlled  by electro mechanic
  • Easy to dismount and mount washing / rinsing arms and filters for cleaning purposes,
  • Safety system to stop the operation when the door is opened  ,
  • Rack dimensions 400 x 400 mms
  • Safety thermostats of  the tank and the boiler ,
  • AISI 304 Cr-Ni  S/S
  • Complete with 1 pc  glass rack
  • When necessary,   the possibility of installing rinsing pump (where water pressure is not sufficient ) and  drain pump where the level of  drain  is high  ,
  • Optional rinsing aid, detergent, draining and booster pump .
  • Lower water level in the tank  controlled by prosesstat automatically while upper water level controlled by electonically  ,

TECHNICAL FEATURES

Water  inlet 3/4 inches
Water pressure 2-4 Bar
Power  inlet 230-50 V-Hz.
Washing Motor Power 0,25 kW
Max. Electric Power 4,15 kW
Frequency 50 Hz
Water Consumption 2,7 Lt/cyc
Tank Power 1,2 kW
Boiler Power 2,6 kW
Washing Temperature 55 °C
Rinsing Temperature 85 °C
Water Inlet Temperature 50-55 °C
Boiler Volume 2,7 lts
Tank  Water Volume 13 lts
Rack   Capacity 40 pcs/h
Glass Capacity 600-800 pcs/h
Program Number 3 pcs
Short Program 90 Secs.
Medium Program 120 secs
Long  Program 180 secs
Cable cross section 3×2,5 mm2
Weight 39 kgs
Rinsing Motor Power 0,33 kW
Draining Motor Power 31 watts
Detergent  Pump Power 8 watts
Rinsing Aid Pump  Power 8 watts

Brand

Inoksan
